High And Low Temperature Humidity Chambers, Environmental Testing Chambers
1. Function and Features
1) The test machine is mainly used in testing the adaptability of electronics, electrical appliances, food, automobile, rubber and plastic, metal and other products, parts and materials in the high and low temperature alternating hot and humid environment when storage, transport and using
2) It is an reliable test equipment for all kinds of electronic, electrical, electronics, plastics raw materials and devices to do testing such as cold, heat, moisture, resistance to dry and the quality control
3) Especially suitable for optical fiber, LCD, crystal, inductor, PCB, batteries, computers, mobile phones, rubber, plastics and other product.
2. Parameters
Inspect standard:JJF-1101,GB/T 10592,GB/T 10586
Testing standards:YD/T 2061,HB 7122.3,6783.7,GJB 5382.7,GJB 150,GB/T 2423,5170.2,5170.5,5179.2, ASTM E512,NF EN 60068-2-38,CNS 12565,12566,KS C0227,KS C022
Specification:
| Model |
LY-280 |
LY-2150 |
LY-2225 |
LY-2408 |
LY-2800 |
LY-21000 |
| Inner Size W×H×D(cm) |
40×50×40 |
50×60×50 |
50×75×60 |
60×85×80 |
100×100×80 |
100×100×100 |
| External Size W×H×D(cm) |
93×155×95 |
100×148×106 |
117×166×118 |
122×176×121 |
158×186×148 |
158×195×168 |
| Volume(L) |
80 L |
150L |
225L |
408L |
800L |
1000L |
| Temp&Humi |
Temp. Range: A: -20°C~150°C
Humi.range: RH20%-98%
|
| Control Range |
B: -40°C~150°C |
| |
C: -60°C~150°C |
| |
D: -70°C~150°C |
| |
(Other temperature and humidity range can be
customized)
|
| Temp&Humi Fluctuation |
±0.5°C;±2.5%RH |
| Temp&Hum Departure |
±0.5°C-±2°C;±3%RH(>75%RH); ±5%RH(≤75%RH) |
| Controller Resolution |
±0.3°C;±2.5%RH |
| Controller Brand |
Korean TEMI880 |
| Material |
Inwall |
SUS 304# steel plate |
| |
Housing |
SUS 304# steel plate surface fog processed |
| |
Heat Insulator |
resistance to high temperature, high chlorine acid
b vinegar foam insulation materials
|
| Aie Circulation Way |
centrifugal fan-broadband type force air circulation |
| Refrigeration Way |
cascade type multiple refrigeration |
| Refrigerater |
fully enclosed piston compressor Taikang France |
| Refrigerants |
R4O4Aor American dupont environmental protection
cold media(R23+R404)
|
| Condensing Way |
Air-cooling |
| Heater |
nickel chrome heating wire heater |
| Humidifier |
semi-closed steam |
| Water Supply Way |
automatic cycle water supply |
| |
|
| Safety Devices |
*Leakage current |
| *Overload |
| *Compressor overload |
| *Over temperature |
| *Ultra-wet/dry |
| *Humidification temperature protection. |
| Power |
380V or 220V AC±10% 50/60Hz |
