Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device

Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device
Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device

Large Image :  Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device

Product Details:
Place of Origin: Guangdong, China
Brand Name: Liyi
Certification: ISO
Model Number: LYH-300D,LYH-600D,LYH-1000D,LYH-2000D
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: Plywood pallet case
Packaging Details: Plywood pallet case
Delivery Time: 1 sets needs 15 days,>1 sets to be negotiated
Payment Terms: T/T
Supply Ability: 100 Set/Sets per Month

Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device

Description
Test Range: 6KN-300kN Displacement Resolution: 0.01mm
Max Drawing Space: 800mm Power Supply: 380V
Max Load: 300KN Test Force Accuracy: 1%
Deformation Test Accuracy: 0.5% Piston Stroke: 250mm
Weight: 2800kg

Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device

Product Description

1. Liyi hydraulic universal testing machine is mainly used to execute the tension, compression, bending, shearing etc. Test for metal materials. Attached simple accessories and devices, it can be used to achieve many kinds of mechanical performances.


2. The oil cylinder is at the bottom of the load frame, tension space is at the upside of the load frame, compression and bending space is between lower cross head and working table. The lower cross head is driven by motor through decelerator, chain transmission device and screw pair, so realize the adjustment of testing space.


3. Liyi hydraulic universal testing machine adopts Load cell measure load, use computer control & display load.



Specifications



Model LYH-300D LYH-600D LYH-1000D LYH-2000D
Max load(kN) 300 600 1000 2000
Test range 6KN-300kN 12KN-600kN 20KN-1000kN 40KN-2000kN
Test force accuracy ±1%
Displacement resolution 0.01mm
Deformation test accuracy ±0.5%
Constant force/ displacement controlling accuracy
SV<10%FS, less than ±1.0% of SV
SV≥10%FS, less than ±0.5% of SV
Deformation rate control accuracy
Rate <0.05%FS, less than ±2.0% of SV
Rate ≥0.05%FS, less than ±0.5% of SV
Max drawing space 800mm 800mm 850mm 800mm
Max compressing space 700mm 700mm 700mm 700mm
Flat sample clamp thickness 0-15mm 0-15mm 0-40mm 0-60mm
Round sample clamp diameter φ6-φ26mm φ13-φ40mm φ13-φ60mm φ13-φ70mm
Bending test branch space 450 mm
Branch width 140mm
Branch diameter 30mm
Piston Stroke 250mm
Clamp method Built-in Hydraulic clamp
Outer demension(mm) 990×600×2435 990×600×2453 1100×770×2490
1160×1100× 2600
Oil 1100×700×950mm
Complete weight 2800kg 3000kg 4700kg 6500kg
Product Effects



Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device

Liyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test DeviceLiyi Servo Motor Testing Machine Metal Universal 300kn Tensile Test Device
