Product Details:
|
| Warranty: | 12 Months, 12 Months | Place Of Origin: | Guangdong, China |
|---|---|---|---|
| Cylinder Height: | 50 Mm | Smooth Metal Roller: | Width: 200 ± 0.5 Mm; Weight: 10 ± 0.5 Kg |
| Weight: | 30kg | Standard: | ASTM |
| Keyword: | Absorption Tester | Absorption Rate: | 75 Mm/10 Min |
| Outside Dimension(L*W*H): | 510*400*365 Mm | Color: | Customer Require |
| Power Supply: | 220V 50HZ | ||
| High Light: | Automatic Cobb Tester,75 Mm Cardboard Paper Testing Instruments,Digital Cardboard Paper Testing Instruments |
||
LIYI Digital ISO535 Cobb Moisture Absorption Tester For Cardboard And Paper
Paper COBB Absorption Tester is mainly used for determination of sized paper and cardboard including surface water imbibition of the corrugated cardboard. The instrument is determination of absorbent paper and cardboard surface, but is not suitable for accurate evaluation of paper or paperboard writing performance.
This test determines the liquid sorption rate of bibulous paper, paperboard, and paper products using gravimetric principles. A set volume of water is dropped onto the paper surface and the time for the drop to be absorbed is measured. The water absorbency rate is used as a measure of the acceptability of tissue, towelling and blotter papers in sorptive tasks.
Other test liquids such as ink, oil and milk are used to assess the comparative performance of papers for specific applications.
Test Standard:
ISO535—1991,GB/T1540—1989 and so on.
| Model | LY-8312 |
| Metal cylinder Inner section Area | 100 ± 0.2 cm^2 (inner diameter is 112.8±0.2mm ) |
| Cylinder height | 50 mm |
| Quantitive Absorption Paper | 200~250 g/m^2 |
| Absorption Rate | 75 mm/10 min |
| Smooth Metal Roller | Width: 200 ± 0.5 mm; Weight: 10 ± 0.5 Kg |
| Environmental Conditions | Temperature: 20~40°c; Relative Humidity: < 85% |
| Outside dimension(L*W*H) | 510*400*365 mm |
| Weight | 30 Kg |
