LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250

China LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250 supplier
LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250 supplier LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250 supplier LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250 supplier LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250 supplier

Large Image :  LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250

Product Details:

Place of Origin: Dongguan
Brand Name: LIYI
Certification: ISO/CE
Model Number: BSYDJ

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Pending negotiation
Packaging Details: plywood case
Delivery Time: 5-20 days
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 100 units per month
Contact Now
Detailed Product Description
Power: Electronic Model Number: LY-BSYDJ
Hardness Value Read: Big Digital LCD Power Supply: AC220V + 5%, 50~60 Hz
Standard: ISO/CE Dwell Time: 1~60S

LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



Product Description:

The Brinell hardness tester is mainly used for the hardness measurement of the materials such as cast iron, steel, non-ferrous metal and soft alloy. The Brinell hardness test is a test method with the largest indentation in all hardness tests, which can reflect the comprehensive performance of the material. It is not affected by the micro-segregation and the inhomogeneities of the sample, so it is a high-precision hardness test method.



Product Overview:

Brinell hardness tester can be used to test castings, forgings, supplied steel, nonferrous metals and semi-finished steel workpieces subject to tempering and heat treatment. It is a portable instrument which can be used in the workshop. It is easy to operate and easily carry. It can test large workpieces on site without sampling.



Operational Principle:

The working principle of Brinell hardness tester is to press the steel ball of a certain diameter into the surface of the sample at a certain speed under the action of a certain test force, and to remove the test force after the specified test force is maintained for a specified time. The Brinell hardness of the metal is expressed by the average pressure on the spherical surface area of the indentation.



Specifications:
Model THUS-250

Switch Type of Objective

lens and Indenter

Auto Turret
Testing Force

10g (0.098N),25g (0.245N),50g (0.49N),100g (0.98N ),200g (1.96N),

300g (2.94N),500g (4.9N),1000g (9.8N)

Scale HV0.01,HV0.025,HV0.05,HV0.1,HV0.2,HV0.3,HV0.5,HV1,HV2
Conversion Scale HRA,HRB,HRC,HRD, HRF,HBW,H15N,H30N,H45N,H15T,H30T,H45T
Min. Measuring Unit 0.01μm
Hardness Value Rang 1HV-4000HV

Hardness Value of

Reading

Digital LCD Screen

Total Magnification of

Microscope

100X(For Observation),400X(For Measurement)

(Can be extended to 200X or 600X)

Loading Method Automatically(Load, dwell and unload the testing force)
Dwell time 1-99s

Specimen Allowing

Maximum Height

85mm
Throat Depth 110mm
Instrument size 405×290×480mm(L×W×H)
Instrument weight 45kg
Light Source

LED Cold light source (can be continuous use for 24 hours, servicing

life can reach 100,000 hours)

Power Supply 110V/220V + 5%, 50/60 Hz
X-Y Testing Table

Dim.:100×100 mm,Max. Travel Range: 25×25mm,Moving Resolution Ratio:0.01mm

(X-Y Digital Testing Table with digital LCD Screen for Optional)

Data Output

Built-in Printer(Hardness Value, The Max. And Min. Value, Testing times and

Average Value)

Built-in RS-232 interface

Executed Standard GB/T4340.2 Chinese Standard, JJG151 Inspection Rules
Standard Accessories

1 piece:

10X Omron digital micro eyepiece ; 10X and 40X objective lens;

Vickers indenter; X-Y Testing Table; Flat Fixture; Thin fixture, Small

Parts Fixture; Level bubble vail; Power Cable; Dust-proof cover;

Instruction Book; Certificate of quality; Warranty Card; Accessory case

2 pieces: Standard block of hardness

4 pieces: horizontal adjusting screw

Optional Purchase

Accessories

Image Analysis Software; Metallographic Structure device;

Knoop Indenter; Knoop Hardness Block; 15X micrometer eyepiece;

2.5X Objective lens; 20X Objective lens; 60X Objective lens



Product Effects



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250





LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



Company Information



LIYI INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 12 years. LIYI products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



LIYI Customized Automatic Digital Brinell Hardness Tester THUS-250



Our Services



If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation manual. We can provide video-con.



1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.



2.Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.



3.Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.



4.Good Packaging:

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
