Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting
Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting

Large Image :  Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting

Product Details:
Place of Origin: CHINA
Brand Name: LIYI
Certification: CE,ISO
Model Number: LY-650A
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Standard export wooden case
Delivery Time: 15 working day
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 50 SET PER ONE MONTH

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting

Description
Laser Power: 15W/20W/30W Testable Material: Laser Capable Precision Materials
Laser Linewidth: Depending On Material And Thickness Laser Wavelength: 355nm/532nm/1064nm
Cutting Format: 350mm*300mm CCD Positioning Accuracy: ±5um @1.3 Megapixels
Laser Cutting Accuracy: ±20um Cutting Thickness: Depending On Power And Material
High Light:

1064nm CO2 Laser Cutting Machine

,

FPC Splitting CO2 Laser Cutting Machine

,

FPC Splitting CO2 Laser Cutter

Double Table Co2 Laser Cutter Plate Metal Nonmetal FPC Splitting Engraving Machine





Introduce:

Laser cutting is to replace the traditional mechanical knife with invisible light beam. It has the characteristics of high precision, fast cutting, not limited to the limitation of cutting pattern, automatic typesetting, material saving, smooth incision, low processing cost and so on. It will gradually improve or replace the traditional metal cutting process equipment. The mechanical part of the laser cutter head has no contact with the workpiece and will not scratch the surface of the workpiece during work; Laser cutting speed is fast, the incision is smooth and flat, and generally there is no need for subsequent processing; The cutting heat affected zone is small, the plate deformation is small, and the cutting seam is narrow (0.1mm~0.3mm); The notch has no mechanical stress and shear burr; High machining accuracy, good repeatability, and no damage to the material surface; NC programming, can process any plan, can cut the whole board with a large format, no need to open a mold, economical and time-saving.





Applications:

FPC/PCB laser plate splitting and cutting; Laser cutting of soft and hard bonding plate; Laser plate splitting and cutting of camera module; Laser cutting of fingerprint packaging chip; Bluetooth headset, intelligent wearable device circuit board, laser splitting, metal / non-metal sheet and other laser precision cutting.





Sample pictures:

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 0 Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 1

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 2 Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 3







Specification:

Item Specification

Laser power

15W/20W/30W...

Laser wavelength

355nm/532nm/1064nm

 Laser linewidth

≤25um(Depending on material and thickness)

Cutting format

350mm*300mm (Double table)

Laser cutting accuracy

±20um

Cutting thickness

≤2mm(Depending on power and material)

XY platform running speed

≤1000mm/s

Positioning accuracy

±5um @1.3 megapixels

Equipment weight

2200kg

Equipment size

1550mm*1700mm*1780mm

Power

220V/50HZ/5KW





Reference Pictures:

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 4



Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 5



Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 6



Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 7



Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 8





Our advantages:

1.15 years professional experience, 8 years Alibaba gold supplier.

2.Supply test equipment to international testing organizations. Such as TUV and SGS.

3.Supply research and development equipment to famous universities.

Such as, University of Cambridge, University of Ghana ,Tsinghua University,National University of defense Technology etc.

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 9



Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 10



Packing: (Use standard export wooden case)

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 11



Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 12



About Factory:

Guangdong LIYI Technology Co.,Ltd is a high technology supported production-oriented enterprise who specializes in developing, manufacturing,marketing all kinds of environmental equipment.Our company has advanced technology, experienced technical management personnel and efficient professional service staffs, fine quality management and perfect after-sales service system.

To strengthen the quality awareness,perfect management system,improve product credit,meet customers increasing requirements, our company brought into ISO9001:2008 international quality management system and obtained the certificate: N0006997-1.Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing indutry.

Double Table CO2 Laser Cutting Machine Plate Metal Nonmetal FPC Splitting 13
