Product Details:
|
| Name: | Products Fastness UV Accelerated Weathering Testing Equipment Machinery | Inside Dimensions: | 45 * 117 * 50 Cm |
|---|---|---|---|
| Outer Dimensions: | 70 * 135 * 145 Cm | Controller: | South Korean Imported Touch Screen Programmable Controller |
| Temperature Range: | RT + 10 °C ~ 70 °C | Rate Of Work: | 4.0 (KW) |
| Himidity Range: | ≥ 95% R.H | Distance Between Lamps: | 35 Mm |
| Distance Between Samples And Lamps: | 50 Mm | Rate of the Lamp: | 40 W |
| High Light: | accelerated uv testing,aging test chamber |
||
Products Fastness UV Accelerated Weathering Testing Equipment with ultraviolet lamps
Application:
UV Accelerated Weathering Tester is the most widely used UV Weathering tester in the world,there
are thousands of ultraviolet aging testers coming into use.
1. The machine can provide reliable aging test data to make the exact prediction of products’ weathering
fastness(aging resistance), which is conducive to sift and optimize the formula. It is used in many industr-ies, such as: paint, inks, resin, plastics, printing and packaging, adhesives, auto and motorcycle industry,
cosmetics, metal, electronic, electroplating, medicine,etc.
2. It can simulate the damage of sunshine, rain, dew to the material quickly and exactly. Damage types
including bleaching, discoloration, loss of light, powder, crack, turbidity, bubble-based, ebrittlement,
strength decline and oxidation need to be engendered in months or years but can engender in a few day
or weeks.
Standards:
It has become the standards of the UV test, fit standards of ISO, ASTM, DIN, JIS, SAE, BS, ANSI, GM, U.S.
GOVT, etc.
Characteristics:
1. According to uses’ operation , it’s easy to operate, safe and reliable.
2.The thickness of specimen installation is adjustable and the specimen installation is fast and convenient.
3.The door rotating up does not interfere with the operation and the tester takes a very small space only.
4. Can be contented by tap water.
5.The heater is under the container rather than in the water, which is long life, easy to maintenance.
6.The water level controller is outside the box, easy to monitor.
7. Provide truckles, convenient to move.
8. Computer programming is convenient, automatically alarming when incorrect operated or faulted.
9. Provide irradiance calibrator to extend the life of the lamp tube(more than 1600h).
10. Have Chinese and English instruction book, convenient to consult.
11. Three types: common, light irradiance controlling, spraying.
Specifications:
|
Model |
LY-ZW |
|
|
Inside Dimensions (CM) |
45 * 117 * 50 cm |
|
|
Outer Dimensions (CM) |
70 * 135 * 145 |
|
|
Rate of Work |
4.0 (KW) |
|
|
Performance Index
|
Temperature Range |
RT+10 °C ~ 70 °C |
|
Humidity Range |
≥ 95 % R.H |
|
|
Distance Between Lamps |
35 mm |
|
|
Distance Between Samples and Lamps |
50 mm |
|
|
Specimen Number |
L300 mm * W75 mm, about 20 pieces |
|
|
Ultraviolet Wavelength |
290nm~400nm UV-340,UV-313,UV-351 (state clearly in your order ) |
|
|
Rate of the Lamp |
40 W |
|
|
Controlling System |
Controller |
South Korean imported touch screen programmable controller |
|
Illumination Heating System |
All independent system, nickel chrome alloy electrical heating type heater |
|
|
Condensation Humidifying System |
Stainless steel shallow evaporative humidifier |
|
|
Blackboard Temperature |
Double metal blackboard meter |
|
|
Water Supplying System |
Humidification water supplying automatic control |
|
|
Exposure Way |
Moisture condensation way exposure, light radiation exposure |
|
|
Safety Device |
Leakage, short circuit, super temperature, water shortage and over current protection |
|
Guangdong LIYI Technology Co.,Ltd is a high technology supported production-oriented enterprise who specializes in developing, manufacturing, marketing all kinds of environmental equipment. Our company has advanced technology, experienced technical management personnel and efficient professional service staffs, fine quality management and perfect after-sales service system.
Our company mainly produce simulated environmental tester, plastic and rubber tester etc. on all kinds of materials testing industries. The production base is located in the country’s manufacturing center Dongguan, Guangdong province, China. In order to service our customers better in terms of reducing costs and early delivery, in 2005 we had set up an office in Kunshan, Jiangsu province for Eastern China marketing and servicing.
Liyi deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.
Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.
During the whole business process, we offer Consultative Selling service.
1)Customer inquiry process:
Discussing testing requirements and technic details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.
2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photoes to show the proucts appearance. Then, confirm the final solution and confirm final price with customer.
3)Order process:
We offer below business term:
| Accepted Delivery Terms | FOB, CFR, CIF, EXW, DDP |
| Accepted Payment Currency | USD, EUR, HKD, CNY |
| Accepted Payment Type | T/T, L/C, Credit Card, PayPal, Western Union, Cash, Escrow |
| Nearest Port | Shenzhen, Guangzhou, Shanghai, Qingdao, Tianjing or rquired |
4)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photoes to show production process.
After finish production, offer photoes to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products in confirmed shipping time and inform customer.
5)Installation and after sale service:
Defines installing those products in the field and providing after-sales support.
