Liyi Tunnel-Type Continuous Hot Air Conveying Dryer Curing Oven Conveyor Belt Type Hot Air Tunnel Furnace Infrared Drying Tunnel

Large Image : Liyi Tunnel-Type Continuous Hot Air Conveying Dryer Curing Oven Conveyor Belt Type Hot Air Tunnel Furnace Infrared Drying Tunnel

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Liyi

Payment & Shipping Terms:

Minimum Order Quantity:	1

Contact Now

Liyi Tunnel-Type Continuous Hot Air Conveying Dryer Curing Oven Conveyor Belt Type Hot Air Tunnel Furnace Infrared Drying Tunnel

Description

Voltage:	220 V, 110 V, 380 V, 480 V	Weight:	200 Kg
Heating Method:	Electric Heating	Conveyor Material:	Green PVC Belt
Effective Drying Length:	6000mm	Feed Port Height:	150mm (adjustable)
Heating Tube:	Stainless Steel U Shape	Body Material:	1.5mm Cold Plate Coating, 304 Stainless Steel
Temperature Range:	RT~250℃ (Adjustable)	Power Source:	AC 380V 3 Phrases 50HZ
Power:	30KW	Boundary Dimension:	L10000W1200H1650
Belt Width:	980mm	Roller Height:	750±30mm
Material Area Height:	Upper 2000mm, Down 2000mm
Highlight:	tunnel-type continuous hot air dryer , conveyor belt curing oven , infrared drying tunnel furnace

Liyi Tunnel-Type Continuous Hot Air Conveying Dryer Curing Oven

Conveyor Belt Type Hot Air Tunnel Furnace Infrared Drying Tunnel

Applications

Hardware, electronics, chemicals, printing, sports equipment, footwear industry, auto parts and more

Specifications

Boundary Dimension	L10000W1200H1650 (can be customized)
Effective Drying Dimension	Total length 6000mm, the height of feed port is 150mm (Adjustable)
PVC Belt Transmission	The width of the belt is 980mm, the roller height from ground is 750±30
The Height of Material Area	Upper area 2000mm, down area 2000mm
The material of the conveyor	Green PVC belt conveyor
The body material	The shell plating is with 1.5mm cold plate coating, the inner plate is with 304 stainless steel plate
Temperature range	RT~250℃ (Adjustable)
Power source	AC 380V 3 Phrases 50HZ
Power	30KW (According to the equipment size and temperature)
Heating Tube	Stainless steel U shape electric heating tube with fins
Wind Carrying Type	Horizontal Wind Up and down wind Right and left wind Three sided wind

Company Profile

Dongguan Liyi Environmental Technology Co., Ltd is a high technology supported production-oriented enterprise specializing in developing, manufacturing, and marketing various environmental equipment. Our company features advanced technology, experienced technical management personnel, efficient professional service staff, fine quality management, and a perfect after-sales service system.

We mainly produce simulated environmental testers, plastic and rubber testers for various materials testing industries. Our production base is located in Dongguan, Guangdong province, China. In 2005, we established an office in Kunshan, Jiangsu province to better serve customers in Eastern China.

Liyi serves customers from more than 150 countries and regions. We are committed to cooperating with dealers worldwide to offer better service. Our mission is to help customers establish testing labs to ensure product quality.

We continue to develop, innovate, and maintain integrity while combining international testing standards with customer-specific demands to establish new benchmarks in the Chinese testing industry.

Frequently Asked Questions

1. Are you Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?

Yes, we are one of the professional and largest manufacturers of environmental chambers, industrial ovens, universal tensile testers, UV aging test chambers, industrial muffle furnaces, paper packing testers, plastic rubber testers, adhesive testers and other testing equipment in China. Every machine purchased from our factory comes with a 12-month warranty after shipment. We offer 12 months of free maintenance, with an additional 2 months extension to account for sea transportation.

If your machine isn't working, you can email or call us. We'll diagnose the problem through conversation or video chat if necessary, and provide a solution within 24 to 48 hours after confirmation.

2. What's the delivery term?

For standard machines, we typically have stock available. If not in stock, delivery time is 15-20 working days after deposit receipt. For urgent needs, we can make special arrangements.

3. Do you accept customization service? Can I have my logo on the machine?

Yes, we offer both standard and customized machines according to your requirements. We provide OEM and ODM services, including adding your logo to the machine.

4. How can I install and use the machine?

After ordering, we'll send you an English operation video via email. Most machines ship fully assembled - you just need to connect the power cable. If needed, we can assist with on-site installation.
